Model Number/SKU: WSD73HWA
Description: 7.3kW split system reverse cycle air conditioner featuring wireless connectivity, inverter compressor, DC fan motor, Super ion filter & bio filter, 3D air flow, Follow-Me, LED remote, demand response capable. 7.3kW cooling/8.3kW heating capacity.
Brand: Westinghouse
Air conditioner type Split system
Type Reverse cycle
Features
Air conditioner features Anti cold air function, remote control, manual operation, economy/sleep mode, auto up/down air swing, auto left/right air swing, auto restart, room temperature display, fan mode, auto mode, air direction control, heating mode, cooling mode, dry mode, self diagnosis, demand-response enabled, low pressure detection, remote control lock, Follow Me, Turbo, sleep mode, wireless enabled
Filtration HEPA, dust filter, ion filter
Remote control Backlit LED remote
Timer 24 hour
Anti-corrosion treatment Gold Shield
Fan speeds Low, medium, high, turbo, auto, silent
Display indicators Temperature, defrost
Performance
Cooling capacity (W) 7300
Heating capacity (W) 8300
Current rating 17.3 amps
Indoor sound level (high) 49 dBA
Indoor sound level (low) 41 dBA
Outdoor sound level 63 dBA
Maximum indoor air circulation 432 L/s
Operating temperature range -15°C to 50°C
Moisture removal 2.16 L/hr
Refrigerant type R32
Refrigerant charge 1400 g
Energy Ratings (ZERL)
Hot climate cooling 4 Stars
Hot climate heating 3.5 Stars
Average climate cooling 3.5 Stars
Average climate heating 3 Stars
Cold climate cooling 4 Stars
Cold climate heating 2.5 Stars
Installation Requirements
Gas pipe size (mm) 15.9
Liquid pipe size (mm) 6.35
Maximum vertical pipe length (m) 25
Maximum total pipe length (m) 50
Additional refrigerant required 12 g/m (beyond supplied charge)
Maximum pipe length with supplied charge (m) 5
Indoor to outdoor wiring 4-wire system
